Forensic Imaging Station – Steampunk Edition

I’ve worked remotely for the past 6 years which means I spend a lot of time in my home office.  Last year we moved into a new house with much better space for my office, and I’ve been shaping it more and more to my tastes.

I do a lot of forensic imaging. I’ve got a pretty basic but rock solid setup that works for me (see Forensic Imaging a Microsoft Surface Pro).  Since I use it frequently I’m hesitant to put it away, but at the same point I don’t like looking at a pile of wires and devices when not in use. That brings us to the latest home office update, the Forensic Imaging Station (Steampunk Edition).

For this project I grabbed a small wooden box from Hobby Lobby.  A good cigar box will also work.  That was going to be my first choice but the only spare box I had on hand said “Corona” on the face and… you know. This box looks nice but it’s composed of mostly particle board, so go slow drilling.

I drilled four holes in the box. A 1/2 inch hole on the front face under the locking clasp for the USB-C cable, and three 5/8 inch holes – 2 on the side and one on the back, to accommodate the rest.

Inside the box I’ve arranged a USB hub connecting:

  • Paladin flash drive
  • External WD hard drive
  • Keyboard (USB)
  • RF dongle for mouse.
  • Pass through for “universal” laptop power adapter
Cheap wood makes for messy holes.

This box had plenty of space to arrange the components. The laptop power adapter comes in the back of the box and then back out on the side.  The USB connector for the hub is also passed through the side. The cable for the keyboard passes through the front.

The finished set-up

The setup is completed with an Azio Retro Compact keyboard, (with replacement copper-edged keys) and a sort of matching mouse.

When it’s time to image, just sit the laptop on top, connect the USB cable and power, and you’re good to go.

Collecting from Microsoft Teams using PowerShell

There are two means by which to ingest Microsoft Teams information into Magnet Axiom for processing. The first approach uses Axiom Process. If you’re collecting in this manner you will need to have the credentials of the user you are collecting from. Axiom will use those credentials to log into O365 and retrieve the user’s data. Depending on the conditions of the investigation, you may have the option of resetting the password to gain access.

Magnet Axiom Cyber Teams Collection

If you don’t have the user’s credentials, but you do have administrative access to the Exchange environment, you can run a search from the Microsoft Security and Compliance center. Once the search completes you can export/download the results as a PST. To ingest the PST into Axiom just ‘add evidence’ , ‘files & folders’ and then browse to the PST file.

To speed up the process, I’ve written a small PowerShell script to build and run the Compliance Center search. The script depends on the ExchangeOnlineManagment module being installed. In this script we’re connecting to Security & Compliance PowerShell using MFA and modern authentication.


The script prompts for:

  • the identity (admin ID) of the investigator
  • a name to save the Compliance search
  • the email address of the user to collecting

Once this information is provided the script will build and run the Compliance Search in O365. From this point you can log into Compliance Center, navigate to the search and then export the contents as a PST.

<# MS Teams Security & Compliance Search
author: Doug Metz
Note this script requires previous installation of the ExchangeOnlineManagement PowerShell module
See for more information.#>
[string]$user = Read-Host -Prompt 'Exchange Credentials'
Connect-IPPSSession -UserPrincipalName $user
[string]$name = Read-Host -Prompt 'Enter a name for the search'
[string]$email = Read-Host -Prompt 'Enter the users email address'
new-compliancesearch -name $name -ExchangeLocation $email -ContentMatchQuery 'kind=microsoftteams','ItemClass=IPM.Note.Microsoft.Conversation','ItemClass=IPM.Note.Microsoft.Missed','ItemClass=IPM.Note.Microsoft.Conversation.Voice','ItemClass=IPM.Note.Microsoft.Missed.Voice','ItemClass=IPM.SkypeTeams.Message'
Start-ComplianceSearch $name
Get-ComplianceSearch $name
New-ComplianceSearchAction -SearchName $name -Export
Write-Host "Search initiated"-ForegroundColor Blue
Write-Host "Proceed to to download the results."-ForegroundColor Blue

Either copy the code from here, or download from my GitHub repository.
